What’s old is new again. In the case of virtualization, truer words have never been spoken. In the past few years, virtualization—a technology commonplace for decades on mainframe systems—has made its way to commodity x86/x64 systems, and its renaissance is changing the way companies do business. Virtualization is a hot technology for many reasons; and if you haven’t considered virtualization, there’s no better time than the present. As is the case with most burgeoning technologies, a lot of confusion exists in the marketplace, starting with the term itself.

Virtualization is one of the most overloaded terms in the recent past. In the most generic sense, it simply means the abstraction of resources. The most popular type of virtualization is machine virtualization, where a virtual machine is presented in software with its own virtual hardware and abstracted from the underlying physical hardware. This allows most x86 workloads to run unmodified within virtual machines, isolated from other workloads, and opens up new ways to deploy and manage software.

Adoption of virtualization is accelerating due to the confluence of three main factors:

• The mainstream adoption of 64-bit (x64) hardware that provides the memory capabilities needed to run multiple workloads concurrently
• The rise of multi-core processors with built-in virtualization hardware assists
• Increased competition, resulting in prices that are dramatically lower (if not free) for high performance, hypervisor-based virtualization

From a benefits standpoint, virtualization offers significant advantages in terms of greater system utilization, lower power consumption, reduced datacenter footprint, ease of deployment, and overall flexibility. You can do more with less, do it more cheaply, and do it faster with more flexibility.

Does this sound too good to be true? Are you skeptical? I hope so.

It’s easy to be swept up in the hype and cut corners in planning and research, resulting in a less-than-optimal experience. Too often, we’ve run into people who have heard about the benefits of virtualization but who don’t understand how it changes other IT aspects such as system and application monitoring, high availability, patch management, backups, and security. Like any disruptive technology, virtualization can provide solutions to many problems but also introduce new challenges. This book is a great way to avoid any pitfalls.

At Microsoft, we listen closely to our customers. One consistent message from is that they want high-performance, easy-to-use, hypervisor-based virtualization. Not a technology that only the high-end enterprises with deep pocketbooks can afford. We agree. With all the benefits that virtualization provides, we want to make this technology available to everyone, whether you’re a small business, in a branch office, or a global Fortune 500 company. Toward that end, we’re pleased to offer Hyper-V both as a role included with Windows Server 2008 and as a free standalone product, Microsoft Hyper-V Server 2008.

Since the Hyper-V release, customer reaction has been overwhelmingly positive, resulting in over 600,000 downloads of Hyper-V technology in just over the first six months of its release. Within Microsoft, Hyper-V has been extensively deployed throughout the company; thousands of Hyper-V virtual machines run a substantial portion of our day-to-day production infrastructure. In addition, if you’ve been to a Microsoft Web site, you’ve most likely interacted with a Hyper-V virtual machine. Why? Because some of Microsoft’s largest Internet sites including TechNet, MSDN (both receive a few million hits per day), and Microsoft.com (more than a billion hits per month) are hosted with Hyper-V. These examples demonstrate the performance, scalable, and reliability that Hyper-V has to offer while running some of the largest Internet properties on the planet.

If you’re not employing virtualization today—if you haven’t tried Hyper-V yet—I strongly urge you to do so with this book in hand. There’s never been a better time to get started, and we have a long roadmap ahead.

—Jeffrey WoolseyPrincipal Group Program Manager, Microsoft Virtualization

Introduction

Welcome to the best book we’ve ever written about Microsoft’s hypervisor technology: Hyper-V! Hyper-V is a foundational virtualization technology released in 2008 by Microsoft, and this book is intended to be a resource for systems administrators looking to use it in a cost effective and efficient manner. Other books may be written about Hyper-V, but no others so far have appeared on the landscape written by those who helped shape or support the product.

The book is meant to cover the essentials of using Hyper-V, giving you the information necessary to get up and running quickly. The book includes technical depth (some not found anywhere else), but it isn’t intended as a comprehensive guide to all aspects of Hyper-V.

What Is Virtualization?

At its simplest, virtualization is the abstraction of computing from computers. Separating software from hardware isn’t a new concept. Administrators have done it for many years on all sorts of platforms. Nearly any system or system component can be somehow pulled away or separated from the hardware or software on which it depends. In Windows-centric environments, complete operating system instances can be virtualized using Hyper-V, Virtual Server, and Virtual PC. Windows systems can also be virtualized with products from other companies, including VMware. This full-system virtualization is only one type of computing abstraction.

Virtualization can happen at nearly any computing boundary within a system. The broad definition and interpretation of virtualization has led to a virtualization frenzy in all forms. It seems as if every software and hardware company has a virtualization offering of some kind. For good or for bad, the word virtualization has been tagged onto products and solutions across the computing industry. It sounds like virtualization is the next great thing in computing. It’s already here, so it actually was the next great thing! In all its present forms, virtualization is providing value to enterprises and individuals and has been doing so for some time.

Microsoft’s Approach to Virtualization

Some software companies address virtualization from a single direction. VMware, for example, focuses on virtualizing and managing operating-system instances. Microsoft has been more thoughtful and less myopic in its approach. Microsoft’s articulated virtualization direction is in five key areas:

• Server—Hyper-V and Virtual Server 2005 for server services
• Desktop—Virtual PC for client-centric, local operating-system instances
• Presentation—Terminal Services providing remote desktop and application access
• Application—SoftGrid/AppV for application encapsulation
• Profile—Roaming profiles for personal-experience encapsulation

All these approaches are tied together by Windows as a platform and managed by the System Center family of products to enable administration of virtual and physical resources.

You can benefit from this multipronged approach to virtualization, which is unified by a common platform and management suite.

It’s All Windows

The great thing about virtualization technology from Microsoft is that it’s integrated with Windows. Windows is a platform well known to administrators and users alike. You don’t need special training to use Microsoft’s virtualization offerings because they’re already familiar. You don’t need to be a virtualization specialist to use Hyper-V, Terminal Services, or AppV (as you might with VMware). You can have virtualization as a competency, just as you might with other focus areas of Windows administration.

System Center Manages All Worlds Well

You manage and monitor each of these virtualization offerings with the same System Center tools that you may already have in your environment for physical system management. Some virtualization-management tools only provide insight into the virtualization layer and can’t dive further into running operating systems or applications (they’re essentially half blind). Using a unified, familiar tool set that can correlate data between physical, virtual, and application software can magnify the benefits of virtualization.

Mixing and Matching with Virtualization

You can use these separate directions of virtualization together with the others to provide more value. You can combine the different focuses of virtualization—server, desktop, presentation, application, and profile—to meet the needs and requirements of changing enterprises. Why not rapidly provision Hyper-V–based virtual machines for thin-client access to meet dynamic demands? How about combining AppV with Terminal Services to alleviate application coexistence issues and reduce server count?

Where Hyper-V Fits

Hyper-V is Microsoft’s efficient hypervisor that enables operating-system virtualization in a server environment. Hyper-V is a core technology pillar of Microsoft’s virtualization strategy and the focus of this book. It’s an installable feature of Window Server 2008 and is available as a no-cost download as Hyper-V Server. Even with other virtualization solutions already installed, Hyper-V can be part of any contemporary Windows Server infrastructure, based on availability and price.

Why We Wrote This Book

Just before the release of Hyper-V, we realized there were few books on the horizon addressing this important and industry-altering technology. We agreed that a book should be written to bring together the combined available information and knowledge we had in developing, using, and managing Hyper-V. We had all read books written by professional authors about technology and felt that the insight of those closer to the product (not professional authors) could serve the needs of administrators well.

Who Should Read This Book

Everyone and anyone interested in understanding Hyper-V and how to use it should read this book. We developed the content specifically for Windows administrators. IT professionals with some experience using Windows Server 2003 or Windows Server 2008 will get the most out of the book. Some chapters are more technical than others, but notes, tips, and pointers to necessary resources are included to make every (aspiring server administrator) reader productive.

Readers are expected to be familiar with Windows and have some experience with and understanding of Windows Server 2008. You don’t need extensive server-administration experience to benefit from the book, only a desire to learn more about Hyper-V and how to use it.

How the Book Is Organized

The book is organized and written with a crawl, walk, run philosophy. We’ll introduce you to server virtualization and Hyper-V administration and then lead you along to expose you to enterprise management concepts and tools for virtualization. We’ve purposely organized the book into three distinct sections to address separate levels of interest and to provide you with three different perspectives on Hyper-V. Each section of the book is written by a different author who has specialized knowledge and expertise in that area.

The first section (Chapters 1 through 5), or the crawling section, is geared toward making you productive with Hyper-V as quickly as possible. These chapters are focused on introducing Hyper-V, setting it up, and running virtual hosts in an efficient and secure manner using little more than the Hyper-V console:

Chapter 1: Introduction to Hyper-V

Chapter 2: Installing Hyper-V and Server Core

Chapter 3: Configuring Hyper-V

Chapter 4: Virtualization Best Practices

Chapter 5: Hyper-V Security

The second, walking section (Chapters 6 through 10) builds on knowledge from the earlier chapters. The middle of the book dives into more advanced manual administration tasks and concepts. Here we wade into complicated and necessary topics including virtual machine migration, backup and recovery, failover clustering, and automation through scripting. We show you how to handle advanced administration tasks manually or through custom automation:

Chapter 6: Virtual Machine Migration

Chapter 7: Backup and Recovery

Chapter 8: High Availability

Chapter 9: Understanding WMI, Scripting, and Hyper-V

Chapter 10: Automating Tasks

The final section of the book (Chapters 11 through 13) is the running or soaring with eagles part of the book. These chapters introduce you to the most effective way to manage an enterprise virtualization environment with several members of the Microsoft System Center family of products. One chapter is devoted to each of three products that are commonly used for server virtualization management (Operations Manager, Virtual Machine Manager, and Data Protection Manager):

Chapter 11: System Center Virtual Machine Manager 2008

Chapter 12: Protecting Virtualized Environments with System Center Data Protection Manager

Chapter 13: System Center Operations Manager 2007

Final Thoughts

The best way to learn about Hyper-V is to be hands-on with it. If you can, take some time to load Windows Server 2008 with Hyper-V on a capable system. This book provides lots of great tips and tricks for using Hyper-V, and trying them firsthand is a great way to develop your understanding and expertise.

Inexpensive systems available today include hardware-assisted virtualization support (as well as x64 support) and make serviceable Hyper-V test systems. You don’t even need new systems for Hyper-V—just a host with Intel VT or AMD-V support. Many of the examples in the book were developed and tested on laptops and desktop systems more than two years old. An older desktop or laptop may not be in any way suitable for production use with Hyper-V, but it can be perfect for you to build a better understanding of this important and useful virtualization technology.
